. . . . . . . . . Rp 2.300.000.- . . . . . . . . . .

Dahua DVR 16 Channel 5 MP

( XVR5116H-i3 )

Dahua XVR5116H-i3 adalah Digital video recorder ( DVR ) 5 MP dengan 16 channel SMD Plus untuk Analog channel , dimana devicenya dapat mengaktifkan alarms secara akurat untuk pergerakan manusia dan kendaraan.

Dahua XVR5116H-i3 mendukung video input HDCVI, AHD, TVI, CVBS dan IP . Serta memiliki 1 bh Port SATA untuk Storage . Dan memiliki 1 bh HDMI ouput serta 1 bh VGA Output.

Dahua DVR ( Digital Video Recorder ) 16 Channel 5 MP ( XVR5116H-i3 )

Spesifikasi Dahua DVR 16 Channel 5 MP ( XVR5116H-i3 ) adalah :

Analog Camera Input : 16 BNC Port Mendukung HDCVI / AHD / TVI / CVBS
Resolusi Camera input CVI : 5 MP@ 25fps , 5 MP@ 20 fps , 5MP @10/12.5 fps , 4MP @ 25/30 fps , 1080p@ 25/30 fps, 720p@50/60 fps , 720p @25/30 fps
Resolusi Camera Input TVI : 5 MP@ 20fps , 4MP @ 25/30 fps , 1080p@ 25/30 fps, 720p @25/30 fps
Resolusi Camera Input AHD : 5 MP@ 20fps , 4MP @ 25/30 fps , 1080p@ 25/30 fps, 720p @25/30 fps
IP Camera Input : Sampai 24 Channel of IPC Access , 8 IP Channel by default + 16 Channel ( Analog Channel bisa dikonversi menjadi IP Channels )
Kapasitas Encoding Main Stream 5 MP Mode : 4 Ch 5MP @ ( 1-fps- 6fps ), Other 5M-N@ ( 1 fps- 12 fps )
Kapasitas Encoding Main Stream 5 M-N Mode : 5M-N@ (1 fps – 12 fps ) , 4M-N / 1080p@ ( 1 fps – 15fps ) , 1080N/ 720p / 960H / D1 / CIF@( 1 fps- 25/30 fps )
Kapasitas Encoding Sub stream : D1/ CIF @ ( 1 fps- 15 fps )
Dual Stream : Didukung
Video Bit Rate : 32 kbps – 6144 kbps
Audio Sampling : 8 kHz , 16 bit
Audio Bit Rate : 64 kbps

Main Processor : Industrial Grade Processor
Operating System : Embedded Linux
Interface Operating : Web, Local GUI
Perimeter Performance AI by Recorder ( Jumlah Channel ) : 2 Channel 10 IVS Rules untuk tiap channel ( Advance Mode ) , 4 Channel 10 IVS rules untuk tiap channel ( General Mode )
Face Detection Atrributes : 6 Attributes
Face Detection Performance dari AI by recorder ( Jumlah Channels ) : 2 Channel ( Up to 12 face image tiap channel )
Kapasitas Face Database : Sampai 10 face database dengan 10.000 images
SMD Plus by Recorder : 16 Channel ( Secondary Filtering untuk manusia dan kendaraan )
SMD Plus By Camera :24 Channels
AI Video Quality Analytics By recorder : 1 Channel
Video Output ; 1x HDMI dan 1x VGA
Multi Screen Display : 1 / 4 / 8 / 9 / 16 ( Ketika IP Mode Extension Disable ) dan 1/ 4/ 8/ 9 / 16/ 25 ( Ketikda IP Extension Mode Enable )
Video Compression : AI Coding, Smart H. 265+ , H.265, Smart H. 264+ , H.264
Audio Compression : G.711a , G.711u , PCM
Protokol Network : HTTP , HTTPS, TCP/IP, Ipv4, Ipv6, RTSP, UDP, NTP, DHCP, DNS, SMTP, UpnP, Ip Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search
Mobile Phone Access : iOS, Android
Recording Mode : General , Alarm, Motion Detection, Intelligent , POS
Playback Recording : 1 / 4 / 9 / 16
Metode Backup : USB Device dan Network
Motede Playback : Instant Playback, General Playback, Event Playback, Tag Playback, Smart Playback
Genreral Alarm : Motion Detection , HDCVI Alarm, Camera External Alarm, Network Alarm, PIR Alarm
Anomaly Alarm : Error , Video Loss, Video Tampering , Camera off line
Intelligent Alarm : Face Deteksi , Face Recognition, Perimeter protetion, SMD Plus
Audio input : 1x Channel RCA , 16 bh Channel BNC
Audio Output : 1x Channel RCA
Interface : 1x SATA Port ( Up to 16 TB ) ,1x RS 475 , 1x USB 2.0 , 1x USB 3.0 , 1x HDMI , 1x VGA , 1x 10/100/1000 Mbps Ethernet Port
Power Supply : 12 VDC, 2A
Konsumsi Power : < 12 waatt
Berat : 1.15 KG
Dimensi : 325 x 257,1 x 55 mm
Garansi : 1 tahun dari Distributor
